Description
Kawasaki Staffa HMC080 — dual-displacement, high-torque low-speed radial piston hydraulic motor, 080 frame: 1,639 cc/rev maximum displacement, 6,560 Nm maximum torque, 138 kW continuous shaft power. Two pre-set displacements, hydraulically selected and changeable while the motor runs — a common anchor windlass and mooring winch drive.
Also known as: hmc080, hmc 080, hmc80, hmc 80, staffa hmc080, staffa hmc 080
Downloads
Manufacturer
Official site: https://www.kawasakihydraulics.com/product/hmc-motors/
Specifications
| frame | 080 |
| series | HMC |
| motor type | Radial Piston (LSHT) |
| max torque nm | 6560 |
| displacement mode | Dual |
| continuous power kw | 138 |
| displacement cc rev | 1639 |
Did you know
- The Kawasaki Staffa HMC series of radial piston motors, which includes the HMC080, has a heritage of over 55 years of successful operation in various applications worldwide. The HMC series itself offers dual displacement capabilities.
- The HMC080 is part of the Kawasaki Staffa HMC series of dual displacement radial piston motors, which ranges from the HMC010 (202 cm³ displacement) to the HMC325 (5330 cm³ displacement), encompassing seven frame sizes. It sits in the middle to lower-middle range of this series in terms of displacement and continuous shaft power.
- The HMC080 is chosen for its high torque at low speeds, smooth running capabilities, and the flexibility of dual displacement, allowing for easy changes in motor displacement even while the motor is running. Its robust design, featuring hydrostatically balanced components, minimizes internal wear and contributes to high efficiency and reliability in demanding marine and industrial applications like anchor windlasses.
| Model | Displacement (Min./Max.) (cm³) | Rated Pressure (bar) | Max. Continuous Torque (Nm) | Continuous Shaft Power (kW) | Weight (kg) |
|---|---|---|---|---|---|
| HMC030 | 98 / 492 | 207 | 1420 | 60 | 100 |
| HMC045 | 153 / 737 | 250 | 2930 | 99 | 150 |
| HMC080 | 153 / 737 | 250 | 6560 | 138 | 150 |
| HMC125 | 164 / 2048 | 250 | 8220 | 135 | 235 |
