Zulu Code Model

Description

^MARL — 30 kW, 6-pole (synchronous 1,000 / 1,200 rpm at 50 / 60 Hz), B5 flange-mounted (large flange with through-holes, horizontal). Standard IEC frame 225M (EN 50347). On a 60 Hz ship nameplate this motor reads about 34.5 kW. Any maker's motor with this rating, pole count and mounting fits the same foot / flange and shaft; a maker's own type for this code is listed as ^MARL.MAKER. Makers sometimes use a larger frame for IE3/IE4 efficiency — check the frame before ordering. Voltage, IP rating and insulation class are ordered as options of the same motor.

Competitive Models

Similar models from other manufacturers — apple to apple.

^MAAA 0.18 kW · 2-pole · B3 foot

^MAAA — 0.18 kW, 2-pole (synchronous 3,000 / 3,600 rpm at 50 / 60 Hz), B3 foot-mounted (horizontal, on feet). Standard I…
^MAAB 0.18 kW · 2-pole · B5 flange

^MAAB — 0.18 kW, 2-pole (synchronous 3,000 / 3,600 rpm at 50 / 60 Hz), B5 flange-mounted (large flange with through-hole…
^MAAC 0.18 kW · 2-pole · B35 foot + flange

^MAAC — 0.18 kW, 2-pole (synchronous 3,000 / 3,600 rpm at 50 / 60 Hz), B35 foot- and flange-mounted. Standard IEC frame …
^MAAD 0.18 kW · 2-pole · B14 face

^MAAD — 0.18 kW, 2-pole (synchronous 3,000 / 3,600 rpm at 50 / 60 Hz), B14 face-mounted (small flange with tapped holes)…
^MAAE 0.18 kW · 2-pole · V1 vertical

^MAAE — 0.18 kW, 2-pole (synchronous 3,000 / 3,600 rpm at 50 / 60 Hz), V1 vertical, flange-mounted, shaft down — the usu…

Send enquiry

Send an enquiry to the manufacturer of ^MARL 30 kW · 6-pole · B5 flange. One broadcast per day.

0 / 5,000

Contribute or correct

Spotted a missing or incorrect entry? Let the maintainers know. Zulu Code is open under CC BY 4.0 — every correction strengthens the standard for the whole industry.

Code map

^M  A  R  L
 │  │  │  └── Model: 30 kW · 6-pole · B5 flange
 │  │  └───── Make: 30 kW (40 HP)
 │  └──────── Equipment: AC Motors (Induction Asynchronous)
 └─────────── System: Motors
