Description
Simrad ES80 — multi-frequency scientific echo sounder for hydrographic survey and deep-sea navigation on research and commercial vessels.
Specifications
| Type | Scientific Echo Sounder |
Did you know
- The Simrad ES80 is the fifth generation professional split-beam fish finder, succeeding the ES60 and ES70 systems. Simrad introduced its first split-beam fish finder in 1984.
- The ES80 is positioned as Simrad's most modern "high-end" split-beam echo sounder in the professional fishery market. It utilizes the same physical units as the Simrad EQ50 echo sounder and the Simrad CP60 current indicator, allowing for modular expansion.
- The ES80's primary strengths include its wideband frequency sweep ('chirp') capabilities, which, combined with advanced signal processing, deliver excellent echo quality and increased resolution over longer ranges. It also offers simultaneous transmission of all frequencies and a high ping rate.
| Model | Operational Frequencies | Split-beam Operation | Wideband Frequency Sweep (Chirp) |
|---|---|---|---|
| ES80 | 10 to 500 kHz | Yes | Yes (FM/CW pulse forms) |
| ES70 | 18, 38, 70, 120, 200 kHz (up to six simultaneously) | Yes | Yes (with specific transducers like ES70-18CD) |
| ES60 | 12 to 200 kHz (up to four channels) | Yes | No (primarily uses CW pulse forms) |
Competitive Models
^NDAA FE-800
Furuno FE-800 — single-beam navigational echo sounder for depth measurement on SOLAS commercial vessels.
^NDAB FCV-1150
Furuno FCV-1150 — combination echo sounder and fish finder with colour display for dual-purpose navigation and fisheries…
^NDAF FE-700
Minted for CS-486 onboarding of IMO 9470040 from the yard's machinery particulars (ECHO SOUNDER SYSTEM p79).
Send enquiry
Send an enquiry to the manufacturer of ^NDBA ES80. One broadcast per day.
Contribute or correct
Spotted a missing or incorrect entry? Let the maintainers know. Zulu Code is open under CC BY 4.0 — every correction strengthens the standard for the whole industry.
Code map
^N D B A │ │ │ └── Model: ES80 │ │ └───── Make: Simrad │ └──────── Equipment: Echo Sounder └─────────── System: Navigation
