Zulu Code Manufacturer

Description

^SBV — 6 V golf-car GC2 case, 6 V, 262 × 180 × 277 mm overall (Trojan Battery's own product pages at trojanbattery.com, BCI group and overall mm: T-105 / T-125 / T-605 / 6V-AGM / T105-AES 261–262 × 179–181 × 273–281 (GC2H, 303 mm high, is a separate taller case)). Any maker's battery in this case at the same capacity fits the same battery space: flooded or maintenance-free, AGM, terminal side and cranking amps are ordered as options. Add the 4th letter for capacity at the 20-hour rate (C20): A 7 · B 12 · C 18 · D 26 · E 33 · F 40 · G 45 · H 50 · I 55 · J 60 · K 65 · L 70 · M 75 · N 80 · P 90 · Q 100 · R 110 · S 120 · T 135 · U 150 · V 165 · W 180 · X 200 · Y 220 · Z 250 — e.g. ^SBVN = 80 Ah. A label printed within 5 mm of this length and width and height is this case. See ^SB for the full key.

Stores Category

Sub-category

^SBV — 6 V golf-car GC2 case, 6 V, 262 × 180 × 277 mm overall (Trojan Battery's own product pages at trojanbattery.com, BCI group and overall mm: T-105 / T-125 / T-605 / 6V-AGM / T105-AES 261–262 × 179–181 × 273–281 (GC2H, 303 mm high, is a separate taller case)). Any maker's battery in this case at the same capacity fits the same battery space: flooded or maintenance-free, AGM, terminal side and cranking amps are ordered as options. Add the 4th letter for capacity at the 20-hour rate (C20): A 7 · B 12 · C 18 · D 26 · E 33 · F 40 · G 45 · H 50 · I 55 · J 60 · K 65 · L 70 · M 75 · N 80 · P 90 · Q 100 · R 110 · S 120 · T 135 · U 150 · V 165 · W 180 · X 200 · Y 220 · Z 250 — e.g. ^SBVN = 80 Ah. A label printed within 5 mm of this length and width and height is this case. See ^SB for the full key.

Competitive Brands

Other manufacturers of the same equipment type.

^SBA JIS B19 · 12 V · 187 × 127 × 202 (227 overall) mm

^SBA — JIS B19 case, 12 V, 187 × 127 mm, box height 202 mm, maximum overall height 227 mm with terminals (as listed in I…
^SBB JIS B24 · 12 V · 238 × 128 × 202 (227 overall) mm

^SBB — JIS B24 case, 12 V, 238 × 128 mm, box height 202 mm, maximum overall height 227 mm with terminals (as listed in I…
^SBX 2 V DIN stationary cell (OPzS / OPzV)

^SBX — 2 V stationary cell to DIN 40736-1 (OPzS, flooded) or DIN 40742 (OPzV, gel). The standard fixes the cell case for…
^SBO Custom case

^SBO — custom: a battery whose case is not one of the ^SB standard cases, including small 12 V standby VRLA blocks (7–10…
^SBZ Other lead-acid

^SBZ — other lead-acid batteries outside the ^SB key: 4 V cells, 24 V packs and traction batteries. Order by the maker's…

Send enquiry

Send an enquiry to the manufacturer of ^SBV 6 V golf-car GC2 · 6 V · 262 × 180 × 277 mm. One broadcast per day.

0 / 5,000

Contribute or correct

Spotted a missing or incorrect entry? Let the maintainers know. Zulu Code is open under CC BY 4.0 — every correction strengthens the standard for the whole industry.

Code map

^S  B  V
 │  │  └── Sub-category: 6 V golf-car GC2 · 6 V · 262 × 180 × 277 mm
 │  └───── Category: Batteries (Lead-Acid & Maintenance-Free)
 └──────── System: Stores
