Description
JRC JCY-2400 — advanced VDR with high-resolution data capture and network integration for modern integrated bridge systems.
Specifications
| Type | VDR (Advanced) |
| Compliance | SOLAS |
Did you know
- The JRC JCY-1900 is JRC's fourth-generation Voyage Data Recorder (VDR), introduced in line with revised VDR performance standards that came into force on July 1, 2014, and updated EPIRB performance standards from July 1, 2022. JRC has been involved in VDR development since 2001.
- The JCY-1900 is a full VDR model, while the JCY-1950 is its Simplified Voyage Data Recorder (S-VDR) variant, designed for vessels that do not require the full VDR capabilities and uses a single capsule. It succeeds earlier models such as the JCY-1700 and JCY-1800.
- The JCY-1900 is chosen for its compliance with the latest VDR performance standards, its integrated Remote Maintenance System (RMS) for remote diagnostics, and its user-friendly 7-inch color LCD touchscreen display for comprehensive system operation and data playback.
| Model | Fixed Capsule Recording | Float-Free Capsule Recording | Internal Storage Recording | Image Recording | Operation Panel Display |
|---|---|---|---|---|---|
| JCY-1900 | 48 hours (32 GB) | 48 hours (64 GB) | 30 days/720 hours (SSD) | 2 radars, 1 ECDIS (max 6 LAN video inputs) | 7-inch color LCD touch screen |
| JCY-1800 | 12 hours (2 GB) | N/A (external) | 30 days (CF card) | 1 (max 2) | 7-segment LED |
Engineering Knowledge
General engineering guidance only — it may contain errors. Always follow the equipment's own documentation and the judgement of a qualified engineer.
MCB’s LED (SYS or REC) does not turn on
Turn on the RCU’s POWER switch. If the AC-line fuse is blowing out, replace it with a spare fuse after stopping power supply to the RCU. Check the switchboard if power supply is not supplied from it. If the PSU is breaking down, contact a sales representative.
OPU’s screen is not displayed
Adjust the screen brightness using the rotary knob. Check the OPU’s operating time; if it exceeds 50,000 hours, replace the OPU and contact a sales representative. If power is not supplied to the OPU, check the LAN cable and reboot the RCU.
OPU can’t operate
If the rotary knob function is in operation mode, push the HOME button on the OPU. If the rotary knob is breaking out, replace the OPU and contact a sales representative.
LCD screen became dark
Adjust the screen brightness using the rotary knob. Check the OPU’s operating time; if it exceeds 50,000 hours, replace the OPU and contact a sales representative.
Data recording stopped (Error 001)
Follow directions from relevant authorities on whether to restart data recording. Refer to the procedure for stopping or restarting recording.
Blackout (Error 002)
Check the switchboard. Turn on the POWER switch. Check the AC line fuse in the RCU; if blown, replace it with a spare fuse.
RCU's built-in battery low voltage (Error 003)
Check the RCU's built-in battery. Turn on the POWER switch and charge the battery.
RCU's built-in fan stopping (Error 004, 005)
Replace the fan. Contact a sales representative.
RCU's built-in battery deteriorating (Error 006)
Replace the battery. Contact a sales representative.
RCU's built-in battery high temperature (Error 007)
Check the temperature of the RCU installation location. Reboot the RCU and verify normal operation; if the problem persists, contact a sales representative.
Competitive Models
Danelec DM100 — voyage data recorder with solid-state capsule and 30-day data storage for SOLAS marine black box complia…
Danelec DM200 — simplified VDR (S-VDR) for smaller SOLAS vessels with reduced recording requirements.
Furuno VR-5000 voyage data recorder — records bridge audio, radar, and ship-sensor data to a protected capsule per IMO c…
Send enquiry
Send an enquiry to the manufacturer of ^NVJB JCY-2400. One broadcast per day.
Contribute or correct
Spotted a missing or incorrect entry? Let the maintainers know. Zulu Code is open under CC BY 4.0 — every correction strengthens the standard for the whole industry.
Code map
^N V J B │ │ │ └── Model: JCY-2400 │ │ └───── Make: JRC │ └──────── Equipment: VDR └─────────── System: Navigation
