Description
Zulu Code has not yet published a description for ^PAKD. Contribute one.
Did you know
- The Grundfos TP/TPE Series of in-line centrifugal pumps has a long heritage, with the TP models being mains-operated and the TPE models featuring electronically controlled motors. The TPE3, a newer addition to the family, was announced in July 2025, expanding the range with highly efficient permanent magnet motors and integrated variable speed drives.
- The TP/TPE series are single-stage, in-line centrifugal pumps, distinguishing them from Grundfos' multi-stage CR series or end-suction NK/NKE pumps. Within the in-line series, TP pumps are the standard, uncontrolled models, while TPE pumps offer electronic speed control through integrated frequency converters, with the TPE3 representing the most advanced and efficient variant.
- The TP/TPE series is chosen for its in-line design, which allows for straight pipework, reducing installation costs and space requirements compared to end-suction pumps. TPE models, in particular, offer significant energy savings (up to 50%) due to their integrated frequency converters and highly efficient motors, making them suitable for applications requiring variable speed control and optimized performance.
| Model | Max Flow (m³/h) | Max Head (m) | Max Liquid Temp (°C) | Motor Efficiency |
|---|---|---|---|---|
| TP/TPE Series (In-Line) | 4500 (50 Hz), 1250 (60 Hz) | 170 (50 Hz), 235 (60 Hz) | 150 | IE3 (TP), IE3/IE4/IE5 (TPE) |
| Grundfos CR Series (Vertical Multi-stage) | 180 | 500 | 180 | IE3/IE4 |
| Grundfos NK/NKE Series (End-Suction) | 2200 | 95 | 140 | IE3/IE4/IE5 |
Competitive Models
^PATA ESC-250
Taiko ESC-250 — centrifugal pump for engine room cooling water and general service duties, 250 m³/h capacity.
^PASA EVZ-200
Shinko EVZ-200 — vertical centrifugal pump for marine cooling water, bilge, and fire service, 200 m³/h capacity.
^PABA VRF Series (Vertical Centrifugal — Ballast / Bilge / Fire)
Vertical single-stage centrifugal pumps for ballast, bilge, fire and general-service duty.
^PAGC SNS Series (Twin-Screw Pump)
^PAGE NB Series (Standardized Centrifugal, EN 733)
Send enquiry
Send an enquiry to the manufacturer of ^PAKD TP/TPE Series (In-Line). One broadcast per day.
Contribute or correct
Spotted a missing or incorrect entry? Let the maintainers know. Zulu Code is open under CC BY 4.0 — every correction strengthens the standard for the whole industry.
Code map
^P A K D │ │ │ └── Model: TP/TPE Series (In-Line) │ │ └───── Make: Grundfos │ └──────── Equipment: Centrifugal Pump └─────────── System: Pumps
