Description
Zulu Code has not yet published a description for ^PAKK. Contribute one.
Did you know
- The Grundfos S/SL Series of submersible sewage pumps are part of a renewed and expanded range of wastewater pumps, continuing the established S, SE, and SL story. These pumps are designed for demanding situations in wastewater management.
- The SL Series is specifically for submerged installations, while the SE Series is designed for both dry and submerged installations. Within the SL and SE ranges, there are variants like the SL1/SE1, which feature the S-tube impeller for high operating hours and large spherical solids passage, and the SLV/SEV, which utilize a SuperVortex impeller for applications with lower operating hours and higher dry matter content.
- The S/SL Series is chosen for its robust design and high efficiency, particularly due to the S-tube impeller, which is engineered to handle varying solids content in wastewater without compromising hydraulic efficiency or free passage. This design aims to provide trouble-free operation, extended pump lifetime, and reduced maintenance.
| Model | Installation Type | Impeller Type | Max Free Passage (mm) | Motor Power (kW) | Max Flow Rate (L/s) | Max Head (m) |
|---|---|---|---|---|---|---|
| SL Series (Sewage Submersible) | Submerged | S-tube / SuperVortex | 35-125 | 0.9-41 | Up to 300 | Up to 80 |
| SE Series (Sewage Submersible) | Submerged or Dry | S-tube / SuperVortex | 35-125 | 9-41 | Up to 280 | Up to 71.3 |
Competitive Models
^PATA ESC-250
Taiko ESC-250 — centrifugal pump for engine room cooling water and general service duties, 250 m³/h capacity.
^PASA EVZ-200
Shinko EVZ-200 — vertical centrifugal pump for marine cooling water, bilge, and fire service, 200 m³/h capacity.
^PABA VRF Series (Vertical Centrifugal — Ballast / Bilge / Fire)
Vertical single-stage centrifugal pumps for ballast, bilge, fire and general-service duty.
^PAGC SNS Series (Twin-Screw Pump)
^PAGE NB Series (Standardized Centrifugal, EN 733)
Send enquiry
Send an enquiry to the manufacturer of ^PAKK S/SL Series (Sewage Submersible). One broadcast per day.
Contribute or correct
Spotted a missing or incorrect entry? Let the maintainers know. Zulu Code is open under CC BY 4.0 — every correction strengthens the standard for the whole industry.
Code map
^P A K K │ │ │ └── Model: S/SL Series (Sewage Submersible) │ │ └───── Make: Grundfos │ └──────── Equipment: Centrifugal Pump └─────────── System: Pumps
