Description
Zulu Code has not yet published a description for ^PAKP. Contribute one.
Did you know
- The Grundfos KP/KPM Series (Split-Case High-Flow) are horizontal split-case pumps. The Unilift KP, a related series, is a single-stage, submersible drainage pump.
- The KP/KPM Series (Split-Case High-Flow) are designed for high flow rates and continuous operation, positioning them for demanding applications in commercial, water utility, and industrial projects. In contrast, the Grundfos NK/NKG series consists of long-coupled, end-suction centrifugal pumps, often used for water supply, industrial pressure boosting, and HVAC systems. The Grundfos S, SE, and SL series are submersible pumps primarily for sewage and wastewater applications, handling solids and featuring specialized impeller designs.
- This series is chosen for its high efficiency, low lifecycle costs, and ease of maintenance due to its axially split design, which allows access to internal components without disturbing the motor or pipework. The double volute design also helps reduce radial load on the shaft, contributing to extended component life and quieter operation.
| Model | Max Flow Rate | Max Head | Liquid Temperature Range | Max Operating Pressure |
|---|---|---|---|---|
| KP/KPM Series (Split-Case High-Flow) | 20,000 gpm (75,700 l/min) | 700 ft (213 m) | -20°F to 275°F (-29°C to 135°C) | 400 psi (27.6 bar) |
| NK/NKG Series (Long-Coupled End-Suction) | 1300 m³/h (5724 gpm) | 160 m (525 ft) (max. 250 m) | -35°C to +140°C (max. 220°C) | 16 bar (232 psi) (max. 25 bar) |
| S Series (Submersible Wastewater) | 39,500 GPM (149,525 l/min) | 300 ft (91 m) | Up to 104°F (40°C) | 130 PSI (9 bar) |
Competitive Models
^PATA ESC-250
Taiko ESC-250 — centrifugal pump for engine room cooling water and general service duties, 250 m³/h capacity.
^PASA EVZ-200
Shinko EVZ-200 — vertical centrifugal pump for marine cooling water, bilge, and fire service, 200 m³/h capacity.
^PABA VRF Series (Vertical Centrifugal — Ballast / Bilge / Fire)
Vertical single-stage centrifugal pumps for ballast, bilge, fire and general-service duty.
^PAGC SNS Series (Twin-Screw Pump)
^PAGE NB Series (Standardized Centrifugal, EN 733)
Send enquiry
Send an enquiry to the manufacturer of ^PAKP KP/KPM Series (Split-Case High-Flow). One broadcast per day.
Contribute or correct
Spotted a missing or incorrect entry? Let the maintainers know. Zulu Code is open under CC BY 4.0 — every correction strengthens the standard for the whole industry.
Code map
^P A K P │ │ │ └── Model: KP/KPM Series (Split-Case High-Flow) │ │ └───── Make: Grundfos │ └──────── Equipment: Centrifugal Pump └─────────── System: Pumps
